Frequency Range (nominal): 30 MHz – 3.0 GHz
Frequency Range (useable): 10 MHz – 3.3 GHz
Coaxial Connector (male): N
Power Supply: 5 V DC < 100 mA
Power Supply and Control Connector: Binder 99-0421-10-07, Series 712 (Other connectors available)
Antenna Factor for E-field strength: 26…33 dB/m
VSWR: typ. 1.3…1.7
Decoupling of the axis: typ. 20 dB
1 dB Compression: 30 MHz: 142.5 dBµV/m/ 300 MHz: 141.0 dBµV/m
Dimensions: 550 × 146 × 146 mm
Weight: 820 g
Environmental Conditions: –10°C to +50°C, IP54
