Impedance:50 Ohm
Frequency range: DC – 18 GHz
Connectors: precision type N, according to MIL-STD-348
Attenuation: 3, 6, 10, 20, 30, 40 dB
Length:56.4 mm (type A), From: 45.2 (3 dB, type B), To: 48.5 mm (40 dB, type B)
Power:5 W / 25°C, 4 W / 45°C, 3 W / 65°C, 2 W / 85°C, 1 W / 105°C, 1 kW peak (5 µsec. pulse width, 0.25% duty cycle)2 W / 85 °C, 1 W / 105 °
VSWR: less than 1.15 (DC – 4 GHz), 1.20 (4 – 8 GHz), 1.25 (8 – 12.4 GHz), 1.35 (12.4 – 18 GH
Normen: MIL-DTL-3933
Body: Stainless steel
