Nominal frequency range: 18 – 40 GHz
Connectors: 50 Ω 2.92
Tube diameter: 22 mm
Gain: typ. 35 dB ± 4 dB
Gain min.: 27 dB
SWR typ.: < 2.6
Max. input power: –20 dBm (87 dBµV)
1 dB compression (at output): > +15 dBm (122 dBµV)
Noise figure: 5.5 dB
DC Power Supply 1: +8 V / 400 mA
DC Power Supply 2: –8 V / 50 mA
Power supply via female safety banana jacks: 4 mm
Dimensions: 370 × 95 × 65 mm
Weight: 0.86 kg
