Nominal Frequency Range: 0.7 – 7 GHz
Usable Frequency Range: 0.4 – 10 GHz
Nominal Impedance: 50 Ω
Connector: N female
Mounting Tube: d=22 mm, Length = 200 mm
Isotropic Gain: typ. 6…15 dBi (0.7 – 7 GHz)
Antenna Factor: 20…34 dB/m
Difference of the Polarisation Planes: ±0.5 dB (f < 4.8 GHz)/±1.5 dB (f > 4.8 GHz)
SWR typ.: 2
Inversion Symmetry: typ. < 0.5 dB
Port Isolation: < –26 dB
Cross Polar Rejection: < –25 dB (typ.)
Max. Input Power: 200 W
Dimensions: 320 × 320 × 615 mm
Weight: 6 kg
