Usable Frequency Range: 3 – 40 GHz
Isotropic Gain: typ. 4 – 16 dBi
Antenna Factor: typ. 35 – 48 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: < 2 (14 – 40 GHz)
Front to Back Ratio: > 20 dB (5 – 40 GHz)
Cross Polarisation: > 20 dB
3 dB Beamwidth typ. (E-Plane): 32°
3 dB Beamwidth typ. (H-Plane): 36°
6 dB Beamwidth typ. (E-Plane): 51°
6 dB Beamwidth typ. (H-Plane): 49°
Max. Input Power: 90 W @ 3 GHz / 25 W @ 40 GHz
Connector: 2.92 mm - Connector female
Mount: 22 mm Tube, Indexing Ring
Length: 216 mm
Width x Length x Height: 124 x 109 (325) x 71 mm
Weight: 0.5 kg
