Frequency Range: 800 MHz ... 6.2 GHz
Isotropic Gain: min 11 dBi (f > 1 GHz)
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR max.: < 2.3 (f > 1 GHz)
Standing Wave Ratio SWR typical: 1.3 (f > 1 GHz)
Polarisation: linear
3 dB Beamwidth typ. (E-Plane): 48° ... 11°
3 dB Beamwidth typ. (H-Plane): 48° ... 12°
Max. Input Power: 1 kW @ 1 GHz, N-Connector female
Max. Input Power:1.7 kW @ 1 GHz , Option: 7-16 connector female
Center Mount: 3/8" + M12
Width x Length x Height: 680 x 435 x 440 mm
Weight: 7.6 kg
