Nominal Frequency Range: 2 … 18 GHz
Usable Frequency Range: 2 … 20 GHz
Isotropic Gain: 9 … 16 dBi (f > 4 GHz)
Antenna Factor: 33 … 41 dB/m (f > 4 GHz)
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: 1.8
Standing Wave Ratio SWR max.: < 4 (f > 4 GHz)
Front to Back Ratio: typ. > 25 dB
Cross Polarisation: typ. > 25 dB
3 dB Beamwidth typ. (E-Plane): 29°
3 dB Beamwidth typ. (H-Plane): 26°
6 dB Beamwidth typ. (E-Plane): 40°
6 dB Beamwidth typ. (H-Plane): 40°
Max. Input Power: 100 W (intermittent), 50 W (continuous)
Connector: SMA-Connector female
Mount: 22 mm Tube, Indexing Ring
Width × Length × Thickness: 98 × 140 (345) × 69 mm
Weight: 0.5 kg
