Nominal Frequency Range: 1.5...10 GHz z
Usable Frequency Range: 1 ... 10.5 GHz
Isotropic Gain: 5 ... 18 dBi
Antenna Factor: 25 ... 33 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: < 1.5
Standing Wave Ratio SWR max.: < 2.5 (f > 1.5 GHz)
Front to Back Ratio: typ. > 25 dB (f > 1.3 GHz)
Cross Polarisation: typ. > 25 dB
3 dB Beamwidth typ. (E-Plane): ≈ 34°
3 dB Beamwidth typ. (H-Plane): ≈ 32°
Max. Input Power: 300 W (cont.)
N-Connector female
Mount: 22 mm Tube, Indexing Ring
Width x Length x Thickness: 184 x 272 (480) x 128 mm
Weight: 1.2 kg
