Nominal Frequency Range: 1 GHz...5 GHz
Usable Frequency Range: 800 MHz ... 10 GHz
Isotropic Gain: 6 ... 14 dBi
Antenna Factor: 22 ... 32 (40) dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: ≈1.5
Front to Back Ratio: > 25 dB (f > 1.3 GHz)
Cross Polarisation: > 25 dB (0.8 GHz...5 GHz)
3 dB Beamwidth typ. (E-Plane): 90°-10°
3 dB Beamwidth typ. (H-Plane): 60°-10°
Max. Input Power: 300 W (cont.) 500 W (peak)
N-Connector female
Mount: 22 mm Tube, Indexing Ring
Width x Length x Thickness: 245 x 220 (408) x 142 mm
Weight: 1.3 kg
