Color: Black
Unit Weight: 1.400 g
REACH - SVHC: Details
Contact Gender: Socket (Female)
Current Rating: 2 A
Mounting Angle: Straight
Mounting Style: Panel
Voltage Rating: 13.5 VDC
Contact Plating: Silver
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder Lug
Flammability Rating: UL 94 V-0
Insulation Resistance: 100 MOhms
Inside Contact Diameter: 3 mm
Outside Contact Diameter: 5.9 mm
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
