Measuring Range Tension: 0.5 – 100.0 cN
Measuring Range Speed: 0 – 1999 m/min
Measuring Range Length: 0 – 1999 m/min
SCHMIDT Calibration Material*: PA: 0.20 mm Ø
Calibration: According SCHMIDT factory procedure
Accuracy: ±1.5 % full scale ±1 digit
Resolution: 0.1 cN
Overload protection: 200 % full scale
Measuring units: cN, gr switchable
Measuring principle: Strain gauge bridge
Damping: Adjustable electronic damping, averaging
Display: LCD 3 ½ digits, 9 mm high
Display update rate: 2 times per second
Auto power off: After 3 minutes off non use
Temperature range: 10 – 45 ºC
Air humidity: 85 % RH, max.
Power supply: LiPo accumulator (approx. 40 h contiunous use, charging time approx. 3.5 h), USB AC adapter 100 – 240 V AC with 4 adapters (EU/USA/UK/AUS-NZ)
Housing material: Aluminium
Dimensions: See dimensions
Weight, net (gross): Approx. 170 g (500 g)
* Suitable for 95 % of applications – PA = Polyamide Monofilament
Delivery Includes: carrying case, USB AC adapter with 4 adapters (EU/USA/UK/AUS-NZ), USB cable, operating instruction in German or English (as requested), Certificate of Compliance with the order 2.1 according EN 10204 free of charge
