Measuring Range: 10 – 50 cN
Take-up Speed: 15 m/min
SCHMIDT Calibration *: PA: 0.12 mm Ø
Calibration: According SCHMIDT factory procedure
Accuracy: ±1 % full scale or ±1 graduation on scale
Scale diameter: 41 mm
Temperature range: 10 – 45 ºC
Air humidity: 85 % RH, max.
Power supply: Take-up wheel: 9 V rechargeable battery with integrated charging electronics with AC adapter 100 – 240 V DC with 4 country adapters (EU, USA, UK, AUS-NZ)
Take-up speed: ~ 15 m/min (MKM-50 and MKM-100); ~ 8 m/min (MKM-400)
Housing material: Tension meter: Plastic (Makrolon); Take-up wheel: aluminium
Dimensions: See dimensions
Weight, net (gross): Approx. 650 g (1250 g)
Other tension ranges available on request.
Other units of measure available, such as g.
* Suitable for 95 % of applications – PA = Polyamide Monofilament
Delivery Includes: transport packaging, AC adapter, operating instruction in German or English (as requested), Certificate of Compliance with the order 2.1 according EN 10204 free of charge
