- Power rating (VA/W): 10000 VA/10000 W
- Input
+ Input voltage range: 110~275 VAC
+ Input frequency range: 40 Hz-70 Hz
+ Input wiring: Single phase with ground
+ Input power factor: ≥0.995
- Output
+ Output voltage: 208/220/230/240 VAC
+ Output voltage tolerance: ±1%
+ Output wiring: Single phase with ground
+ Output connection: 2*IEC, 1*Terminal Block
+ Output frequency rang: 50/60Hz±0.1Hz (battery mode)
+ Output THDV: <1% (linear load) <5% (non-linear load)
+ Output waveform: Pure sinewave
+ Overload capability: 10min @ 105~125% load
30S @ 125~150% load
0.5S @ >150% load
- Battery and charger
+ Battery quantity: 16PCS default, 16/17/18/19/20 adjustable
+ Recharge time to 90% battery capacity: depends on customer configuration
+ Backup time: depends on customer configuration
+ Recharge current: 4A default, 0-12A adjustable
- Display:
+ LCD+LED: load rating/battery capacity/input/output/operating mode
- Communication and monitoring
+ Communication port: RS232, USB+EPO, Dry in/Dry out configurable.
+ Extendable communication card: Dry Contact Card, MODBUS Card, NMC Card are optional
+ Software: Winpower
- Physical parameters
+ Product dimension (W*H*D) mm: 438* 86.3* 573 mm
+ Product weight (Kg): 16
- Environment
+ Operating temperature: 0-40ºC
+ Operating humidity: 0-95% (non-condensing)
- Standar: IEC62040, IEC60950
