Detecting method: Magnetic induction
Detecting ability: Steel ball φ1.2,φ1.5,φ2.5
Detecting area/ Passing width: 1500mm
Passing height: 150mm standard (with guide: passing height 130mm)
Alarm device: Buzzer, lamp, belt stop (with backward run function)
Belt speed: 25m/min. (50Hz, 60Hz)
Power source: AC200V, 3 phase 50/60Hz about 600VA
Dimensions: 2000(D)×1080±50(H)×2500(W)
Weight: ≈700kg
Pass line: 800±50mm
Option: foot SW, remote SW, auxiliary SW
Single belt use with the specifications
