Frequency Range 300kHz~8Ghz
Effective directivity 45 dB
Effective source match 40 dB
Power range -60 dBm to +10dBm（300 kHz to 6Hz）
-60 dBm to +5 dBm （6GHz to 8GHz）
Damage DC voltage + 35V
Sweep Point 2 - 10001
Measurement time per point 100 ms
Measured parameters S11, S12, S21 & S22
Display 10.4 inch TFT color LCD, touch screen
Interfaces VGA, GPIB(option), USB, LAN
Power supply 220 ± 22 V (AC), 50 Hz
Dimensions (W x H x D) 440 x 231 x 360 mm
Weight 12.5kg
