Frequency Range: 100 kHz to 26.5 GHz
Frequency Resolution: 0.1 Hz
Frequency Accuracy: ±1×10-7 (23℃±3℃)
Max. Output Power:
2-port:
100kHz – 10MHz: +5dBm
10MHz – 4GHz: +15dBm
4GHz – 10GHz: +15dBm
10GHz – 14GHz: +10dBm
14GHz – 20GHz: +9dBm
20GHz – 24GHz: +6dBm
24GHz – 26.5GHz: 0dBm
4-port:
100kHz – 10MHz: +3dBm
10MHz – 4GHz: +13dBm
4GHz – 10GHz: +10dBm
10GHz – 14GHz: +4dBm
14GHz – 20GHz: +3dBm
20GHz – 24GHz: -2dBm
24GHz – 26.5GHz: -6dBm
Power Sweep Range
2-port
100kHz – 10MHz: 40dB
10MHz – 20GHz: 45dB
20GHz – 26.5GHz: 40dB
4-port
100kHz – 10MHz: 40dB
10MHz – 20GHz: 38dB
20GHz – 26.5GHz: 34dB
Dynamic Range
2-port
100kHz – 10MHz: 102dB
10MHz – 4GHz: 132dB
4GHz – 10GHz: 133dB
10GHz – 14GHz: 125dB
14GHz – 20GHz: 124dB
20GHz – 24GHz: 120dB
24GHz – 26.5GHz: 115dB
4-port
100kHz – 10MHz: 102dB
10MHz – 4GHz: 132dB
4GHz – 10GHz: 130dB
10GHz – 14GHz: 120dB
14GHz – 20GHz: 119dB
20GHz – 24GHz: 115dB
24GHz – 26.5GHz: 110dB
Effective Directivity: 48dB (100kHz – 2GHz), 44dB (2GHz – 20GHz), 44dB (20GHz – 26.5GHz)
Transmission Tracking: ±0.10dB (100kHz – 100MHz), ±0.08dB (100MHz – 20GHz), ±0.10dB (20GHz – 26.5GHz)
Port Connection: 3.5mm (male)
Number Of Measuring Ports: standard 2 port, optional 4 port
Peripheral Interface: USB, GPIB, VGA, LAN, HDMI interface
Display: 12.1-inch 16:10 screen (equipped with capacitive touch function)
Power Consumption: Maximum 300W
Dimension
426 (W) × 266 (H) × 400 (D) mm (no soles, no handles)
516 (W) × 280 (H) × 490 (D) mm (include soles and handles)
Weight: max. 25kg
