Frequency Range: 3Hz to 4GHz
Span:
Range: 0Hz (zero span), 10Hz – the highest frequency of the model
Accuracy: ± (0.1%× span＋span/ (sweep points number-1))
Sweep Time Range:
Span≥10Hz: 1ms – 6000s
Span=0Hz: 1us – 6000s
RBW: 1Hz-3MHz (step by 1, 2 ,3 ,5) / 4 MHz / 5 MHz / 6 MHz / 8 MHz / 10MHz / 20MHz
VBW: 1Hz-3MHz (step by 1, 2 ,3 ,5) / 4 MHz / 5 MHz / 6 MHz / 8 MHz / 10MHz / 20MHz
Signal Analysis Bandwidth:
10 Hz – 10 MHz (Standard)
40 MHz (Optional)
200 MHz (Optional)
550 MHz (Optional)
SSB Phase Noise:
-96 dBc/Hz @ 100Hz offset
-115 dBc/Hz @ 1kHz offset
-125 dBc/Hz @ 10kHz offset
-125 dBc/Hz @ 100kHz offset
Trigger Source: Free, Line, Video, External level (front panel), External level (back panel), Burst RF, Timer
Input Connector: N (female), impedance: 50Ω
Power Supply: AC 100 – 240V: 50 – 60Hz
Dimension:
Excluding the handle, brackets: 426 (W) × 177 (H) × 460 (D) mm
Including the handle, brackets: 510 (W) × 190 (H) × 534 (D) mm
Weight: About 25kg
