Measuring range (mm): 0.5~10000
Frequency range (MHz): 0.5~20
Pulse shift (μs): -20~+3400
Vertical linearity error: ≤2.5%
Horizontal linearity error: ≤0.1%
Gain (dB): 0~120
Zero (μs): 0.0~99.99
Material velocity: 1000~15000 m/s
Sensitivity margin: ≥60dB
Dynamic scope: ≥32dB
Measurement mode: single, dual, THRU
Reject: 0~80%
Port type: BNC(Q9)
Memory: 300
Independence setup: 100
Make video: 5 min
Continue working time: 10h
Display: LED True Color
Operating temperature: -20~55°C
Dimension: 240mm×180mm×50mm
Net weight: 1.8kg
Standards: JB/T 10061-1999, JJG 746-2004
