Temperature Control Precision: ±0.01℃
Temperature Range: Room Temperature～100℃
Instrument Weight: 28kg
Ambient Humidity: ≤85%
Operating Temperature: 5℃～40℃
Storage Temperature: 0～50℃
Heating Power: 1500W
Heating Method: Electric heating unit
Temperature Control Mode: PID regulation
Liquid Level Detection: Infrared photoelectric detection
Overall Dimension: 370×300×650mm
Display: 7-inch touch LCD
Working Power Supply: AC 220V 50Hz
Resolution: 0.01℃
Viscosity Resolution: 0.00001mm²/s
Insulating Oil Viscosity Test Kit: Petroleum Oil Kinematic Viscosity Testing Equipment
The working principle is to put the sample into the selected capillary viscometer, the capillary immersed in the constant temperature bath. The sample will be sucked into the calibration position. When the sample flows to the upper calibration position, the instrument will start recording time automatically.
Features about the Density Kinematic Viscosity Index Tester
1.Easy Operation
2.Complete the kinematic viscosity test by One Press
3.16 Sets of preset parameters are available. Preset parameters are modifiable.
4.A and B dual-channel test, parameters can be set separately, and the test does not interfere with each other at the same time, saving time for multiple liquid measurement;
5.Infrared liquid level detection is not interfered by indoor light and light;
6.The position of liquid level detection can be adjusted and freely;
7.Modular design, high stability and reliability;
8.Automatically store 100 test results, and view or print them at any time
9.The testing process complies with the standard and the data is reliable, good repeatability.
10.The product is in our Insulating Oil Viscosity Test Kit.
