Measuring Range
Output Current: 100A, 80A, 50A, 30A
Measuring Range (100A): 0~2000μΩ
Measuring Range (80A): 0~5mΩ
Measuring Range (50A): 0~10mΩ
Measuring Range (30A): 0~20mΩ
Technical Index
Accuracy: ± (Reading × 0.5% + 1μΩ)
Resolution Ratio: 0.1μΩ
Display Digit: Four and a half digits
Test Power Supply: Constant current limit voltage, about 2V
Input Voltage: Maximum 5V
Measuring Time: Quick, 10~60 seconds optional
Testing Times: More than 600 times (full charge, fast measurement mode)
Test Line: Resistance less than 10mΩ
Conditions of Use and Shape
Working Power Supply: Built-in lithium battery or external charger, charger input 100~240VAC, 50Hz/60Hz
Charging Voltage: 12.6V
Charging Current: ≤3A
Charging Time: About 3 hours
Auto Shut Off: 5 minutes automatic shutdown without operation
Instrument Weight: 1.7kg (exclude test lines)
Instrument Dimension: 246mm (L) × 156mm (W) × 62mm (H)
Environment Temperature: -10℃~50℃
Relative Humidity: ≤90%, no dew
Features of Digital 100A Winding Resistance Tester
1. Lithium battery power supply, a charge can be continuously tested more than 600 times, the test process is simple and
2. The maximum output current is 100 A, multi-stage current is optional, and the test range is wide.
3. When doing 100A test, the longest test time can be up to 60 seconds, which can satisfy various field applications.
4. The measuring range is wide and the precision is high. At 100A, it can reach 2000μΩ.
5. Has the open circuit protection, overheating protection and so on perfect protection function.
6. 6 inch super-industrial-grade high-brightness color LCD screen, in strong sunlight display is still clearly visible.
7. Equipped with external printer, easy to print data.
8. With native storage and USB disk storage, easy to save data.
