Number of output channels: 4
Total output power: Max 800 W
Maximum output power/CH: 200 W
Output voltage/CH: 0 V to 64 V
Output current/CH: 0 A - 10 A
Voltage ripple and noise: 20 Hz to 20 MHz: < 3 mV (RMS), < 30 mV (Vpp) (meas.)
Current ripple and noise: 20 Hz to 20 MHz: < 3.5 mA (RMS) (meas.)
Load regulation: load change: 10% to 90%
Voltage: < 0.01% + 10 mV
Current: < 0.01% + 5 mV
Programming accuracy:
Voltage: < 0.05% + 10 mV
Current: < 0.1% + 10 mA
Display: TFT 5" 800 × 480 pixel WVGA touch
Interfaces: USB-TMC, USB-CDC (Virtual COM), LAN
Temperature:
Operating temperature range: +5°C to +40°C
Storage temperature range: –20°C to +70°C
Humidity: noncondensing 5% to 95%
Mains nominal voltage: 100 V to 250 V
Mains frequency: 50 Hz to 60 Hz
Maximum power consumption: 650 W
Dimensions: W × H × D 362 mm × 100 mm × 451 mm (14.25 in × 3.94 in × 17.76 in)
Weight: 7.5 kg (16.5 lb)
Accessories supplied:
Base unit
Set of power cables
Terminal blocks
Quick start guide
