Analog Bandwidth (50 Ω, -3 dB): 200 MHz
Analog Bandwidth (1MΩ, -3 dB): 200 MHz
Calculated Rise Time under 50 Ω (10% to 90%, typical): ≤1.75 ns
Input Channels: 4 analog channel inputs, 1 EXT channel input
Sampling Mode: Real-time sampling
Max. Sample Rate of Analog Channels: 4 GSa/s (single channel), 2 GSa/s (half channels), 1 GSa/s (all channels)
Note: The sample rate reaches 1 GSa/s when all channels are enabled. For HDO4804 series, the maximum analog bandwidth is only 400 MHz
Max. Memory Depth
Standard: 250 Mpts (single channel), 125 Mpts (half channels), 62.5 Mpts (all channels)
Optional: 500 Mpts (single channel), 250 Mpts (half channels), 125 Mpts (all channels)
Max. Waveform Capture Rate: 50,000 wfms/s (Vector Mode)/ 1,500,000 wfms/s (UltraAcquire Mode)
Vertical Resolution: 12 bit
Hardware Real-time Waveform Recording and Playing: Up to 500,000 frames
Peak Detect: Capture glitches as narrow as 500 ps
Display Size and Type: 10.1-inch capacitive multi-touch display
