Width: 10 mm
Height: 4.5 mm
Length: 15 mm
Fall Time: 7.7 ns
Rise Time: 8.6 ns
Technology: Si
Channel Mode: Enhancement
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 23 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 29.5 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 13.3 ns
Typical Turn-Off Delay Time: 37.6 ns
Id - Continuous Drain Current: 10 A
Maximum Operating Temperature: + 150 C
Rds On - Drain-Source Resistance: 850 mOhms
Vds - Drain-Source Breakdown Voltage: 500 V
Vgs th - Gate-Source Threshold Voltage: 5 V
