Core: RX
Width: 7 mm
Height: 1.05 mm
Length: 7 mm
Data RAM Size: 64 kB
Data RAM Type: RAM
Data ROM Size: 512 kB
Data ROM Type: ROM
ADC Resolution: 12 bit
DAC Resolution: 12 bit
Data Bus Width: 32 bit
Interface Type: I2C, SCI, USB
Mounting Style: SMD/SMT
Number of I/Os: 82 I/O
Watchdog Timers: Watchdog Timer
Processor Series: RX113
Moisture Sensitive: Yes
Program Memory Size: 8 kB
Program Memory Type: Flash
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Number of ADC Channels: 17 Channel
Maximum Clock Frequency: 32 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
