Core: RL78
Width: 3 mm
Height: 0.76 mm
Length: 3 mm
Data RAM Size: 3 kB
Data RAM Type: SRAM
ADC Resolution: 8 bit/10 bit
Data Bus Width: 16 bit
Interface Type: I2C, UART
Mounting Style: SMD/SMT
Number of I/Os: 21 I/O
Watchdog Timers: Watchdog Timer, Windowed
Processor Series: RL78/G13
Moisture Sensitive: Yes
Program Memory Size: 48 kB
Program Memory Type: Flash
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.6 V
Analog Supply Voltage: 1.6 V to 5.5 V
Number of ADC Channels: 6 Channel
Maximum Clock Frequency: 32 MHz
Number of Timers/Counters: 8 x 16 bit
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
