RECOM Power REC30-2412S Isolated 30W 18-36Vin 12Vout 2500mA

Width: 40.6 mm (1.598 in)

Height: 10.2 mm (0.402 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Compliance: CAN/CSA; IEC; REACH; RoHS; UL

Efficiency: 90%

Unit Weight: 48 g

Output Power: 30 W

Input Voltage: 18 V to 36 V

Mounting Style: Through Hole

Isolation Voltage: 1.6 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 24 V

Standard Packaging Size: 2 x 1.6

Output Current-Channel 1: 2.5 A

Output Voltage-Channel 1: 12 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
