Width: 53 mm (2.087 in)
Height: 31.5 mm (1.24 in)
Length: 78.4 mm (3.087 in)
Industry: Medical, Industrial
Dimensions: 78.4 mm x 53 mm x 31.5 mm
Efficiency: 89 %
Output Power: 40 W
Input Voltage: 80 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: PCB
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 8 A
Output Voltage-Channel 1: 5 VDC
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
