RECOM Power RAC150-24SG/OF AC-DC Converter 120W 90-264Vin 24Vout 6.25A

Width: 50.8 mm (2 in)

Height: 30 mm (1.181 in)

Length: 101.6 mm (4 in)

Industry: Industrial

Compliance: CAN/CSA; CE; EAC; ERP; FCC; IEC; RoHS; UL

Efficiency: 91 %

Unit Weight: 200 g

Output Power: 150 W

Input Voltage: 90 VAC to 264 VAC

Mounting Style: Chassis

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Isolation Voltage: 3 kVAC

Number of Outputs: 1 Output

Input Voltage - Max: 264 VAC

Input Voltage - Min: 90 VAC

Open Frame/Enclosed: Open Frame

Standard Packaging Size: 4 x 2

Output Current-Channel 1: 6.25 A

Output Voltage-Channel 1: 24 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 30 C
