Width: 25.5 mm
Height: 16.4 mm
Length: 50.9 mm
Industry: Industrial
Approvals: EN60950-1, UL60950-1
Compliance: CAN/CSA; CE; EAC; ERP; IEC; RoHS; UL
Efficiency: 75%
Unit Weight: 35 g
Output Power: 6 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: PCB
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 264 VAC
Input Voltage - Min: 80 VAC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 1.2 A
Output Voltage-Channel 1: 5 VDC
Maximum Operating Temperature: + 55 C
Minimum Operating Temperature: - 25 C
