Width: 27.2 mm
Height: 17.1 mm
Length: 36.7 mm
Industry: Industrial
Approvals: EN60950-1, IEC60950-1, UL60950-1
Compliance: CAN/CSA; EAC; ERP; IEC; RoHS; UL
Dimensions: 36.7 mm x 27.2 mm x 17.1 mm
Efficiency: 79%
Unit Weight: 41.223 g
Output Power: 4 W
Input Voltage: 80 VAC to 305 VAC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Isolation Voltage: 3.75 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 305 VAC
Input Voltage - Min: 80 VAC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 267 mA
Output Voltage-Channel 1: 15 VDC
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 40 C
