Nominal Force (KN): 1600
Stroke of Nominal Force (mm): 8
Stroke of Sliding Block (mm): 160
Number of Strokers (times/min): 28
Closed Height (mm): 400
Closed Height Adjustment (mm): 120
Distance From Slider Block Centre To the Frame (mm): 390
Length Between Columns (mm): 580
Hole Size for Die Handle:
+ Diameter (mm): 80
+ Depth (mm): 150
Size Of Worktable:
+ Left - right (mm): 1140
+ Front - Back (mm): 740
Blanking Hole Diameter (mm): 200
Table Plate Thickness (mm): 150
The Maximum Tilt Angle (°): -
Dimensions:
+ Left - right (mm): 1855
+ Front - Back (mm): 2045
+ Height (mm): 2920
Power (KW): 15
