Performance Indicators
Detector Type: Uncooled VOx infrared detector
Resolution: 256×192
Detector Frame Rate: 25Hz
Pixel Pitch: 12μm
Spectral Band: 8~14μm
NETD: ≤50mK at 25°C (≤40mK, optional)
Image Adjustment
Brightness/Contrast Adjustment: Manual/Auto
Polarity: Black-hot/White-hot
Palette: Multiple types support
Reticle: Display/Blank/Move
Image Processing: Digital filtering noise reduction, and digital detail enhancement
Mirroring: Horizontal/Vertical/Diagonal
Power Supply
Power Supply Range (typical): 3.8V~5.2V
Typical Power Consumption at 25°C Without Extension: ≤0.35W
Interface
Digital Video: CDS2/CDS3/LVCMOS
Serial Communication Interface: UART
Extension Components: Analog Video
Interface/Supporting
Direct Drive Solution: Compatible with SOC platforms such as HIS13516, HIS13519, NT98528, AR9201, AR9341, and CV28M33
Temperature Measurement Performance
Measurement Range: Temperature measurement series: -20℃~+550℃
Measurement Accuracy: For measurement series, ±3°C or ±3% of reading (The greater shall prevail) @Ambient temperature of -20°C~+60°C
Physical Characteristics
Dimensions (Without lens and extension components): 21×14.6mm
Weight (3.2mm, without extension components): ≤3.5g
Lens Model: 2mm, 3.2mm, 7mm, 10mm, 13mm
Environment Adaptability
Operating Temperature: -20℃~60℃
Storage Temperature: -45℃~+85℃
Humidity: 5 ~ 95%, non-condensing
