Thermal Imaging Parameters
Detector Type: Uncooled infrared detector
Infrared Resolution: 640×512
Spectral Band: 7.0-8.5μm
Gases Detectable: Methane, nitrous oxide, sulfur dioxide, phenol, ethyl acrylate, 2-ethylhexyl acrylate, freon (R13, R13B1, R123, R125, R134A, R417A, R422A, R508A)
Pixel Size: 12μm
Thermal Sensitivity (NETD): 23mK
Spatial Resolution (IFOV): 0.63mrad
Image Frequency: 30Hz
Lens Focal Length: 19mm
Field of view (FOV): 23°×18°
Object Temperature Range: -20°C~+120°C
Temperature Accuracy: ±2% or ±2°C
Camera Functions
Temperature Measurement Mode: Center point/Hot and cold spot tracking and temperature display
Customized Measurement on Points, Lines, and Areas: Movable points/lines/areas; up to 10 points, 10 areas, and 10 lines
Measurement Unit: Celsius, Fahrenheit, Kelvin
Emissivity Settings: 0.01~1.00, step size 0.01
Ambient Temperature Settings: -10°C~+50°C, step size 1°C
Distance Settings: 1~20m, step size 1m
Image Mode: Infrared, visible light, dual-spectrum fusion, PIP
Palettes: 10
Temperature Alarm: Available
Alarm Type: Image Alarm
Temperature Width Stretch: Manual/Auto temperature range
Laser Pointer: Available
Visible Light Camera: 5 megapixels
Video/Photo Storage: XX-IR.jpg (Infrared image with temperature data) and XX-DC.jpg (visible-light image); videos without data.
Voice Note: Available
Language: English, Japanese, Poland, Russian, Korean, Hungarian, Bap, German, French,Spain, Italy, Turkey, and Traditional Chinese
Display Size: 3.5-inch touch screen (480×640)
Image Naming: Auto/manual naming, naming by scanning QR code
Memory Card: Standard 32GB Micro SD card
Battery Type: Rechargeable and detachable lithium-ion battery
Power Supply: USB TypeC
Connecting Method: USB, SD card, Wi-Fi (AP mode or networking mode)
Battery Charging Time: About 3h
Battery Operating Time: About 3h
Power Management: Automatic shutdown: 5 minutes, 10 minutes, 20 minutes, never
Others
Analysis Software: PC & App
Tripod Support: Available
Operating Temperature: -10°C~+50°C
Storage Temperature: -20°C~+60°C
Relative Humidity: 10%~95%, non-condensing
Drop Protection: 2m
Ingress Protection Rating: IP54(IEC 60529)
Shock and Vibration: Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Dimensions: 256.4×105.1×105.3(mm)
Weight: About 670g
Packing List: 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger
