Thermal Module
Detector Type: VOx, uncooled FPA detectors
Spectral Range: 8~14μm
NETD: ≤40mK(@25°C,F#1.0,25Hz)
Resolution: 640×512
Pixel Pitch: 12μm
Focal Length: 30~150mm/25~225mm
Optical Module
Sensor: 4MP 1/1.8" Progressive Scan CMOS
Resolution: 2688×1520
Focal Length: 15~775mm, 52x
PTZ
Pan: 360° continuous，0.01°~120°/s
Tilt: -90°~+90°，0.01°~60°/s
Preset: 1024
Scan mode: Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan
Wiper: wiper
Smart Function
Fire Detection: Support
Smoke Detection: support
VCA: Support Line Crossing & Intrusion detection
2-Way Audio: Support
Linkage Action: Video/ Snapshot/Email/Alarm output
System Interface
Power: DC 48V±15%
Network: 1 RJ45 10M / 100M self-adaptive Ethernet port
Audio: 1 in/1 out
Alarm: 7 in/2 out
Storage: Micro SD memory（maximum 256G）
Serial Port: 1 channel RS485, can support Pelco protocol
General
Work Environment: -40℃~+70℃；<90%RH
Protection: IP66
Power Consumption: max. 160W
Dimenstion(mm): 620×854×525
Weight: 80kg
