Metrological parameters
-Maximum capacity [Max]: 220g
-Minimum load: 10mg
-Readability [d]: 0.1 mg
-Verification unit [e]: 1mg
-Tare range: -220 g
-Standard repeatability [5% Max]: 0.06 mg
-Standard repeatability [Max]: 0.07 mg
-Standard minimum weight (USP): 120 mg
-Standard minimum weight (U=1%, k=2): 12 mg
-Permissible repeatability [5% Max]: 0.09 mg
-Permissible repeatability [Max]: 0.1 mg
-Linearity: ±0.2mg
-Stabilization time: 2s
-Adjustment: internal (automatic)
-OIML Class: -
Physical parameters
-Leveling system: semi-automatic - LevelSENSING
-Display: 5″ graphic colour touchscreen
-Weighing chaber door: manual
-Delivery components: Balance, weighing pan, weighing pan shield, centring ring, bottom cover, power supply, fabric dust cover
-Weighing chamber dimensions: 190×190×222mm
-Weighing pan dimensions: ø100 mm
- Net weight: 7.06kg
- Gross weight: 8.5 kg
- Protection class: IP 43
- Database capacity: 7
- Touch-free operation: 2 IR Sensors
Communication interface
-Communication interface: RS232¹, 2×USB-A (interchangeable), USB-B, Wi-Fi®, Ethernet
-Electrical parameters: Power supply
Adapter: 100 – 240V AC 50/60Hz 0.6A; 12V DC 1.2A
Balance: 12 – 15V DC 0.8A max
Power consumption max.: 4 W
Operating temperature: +10 — +40 °C
Ambient conditions monitoring (option): THBR 2.0 System, THBR BOX, THB P, THB W, THB S
Relative humidity: 40% — 80%
