Range (bar): -1 to 1
Resolution (bar): 0.0001
Units : bar, kg/cm², MPa, mH2O, atm, psi, inHg, ftH2O, kPa,inH2O, mmHg, mbar, cmH2O, mmH2O
Hand pump range : HP-1 (-0.95 to 1 bar)
Over Pressure Alarm: 20% of Full Scale (up to 40 bar), 5% of Full Scale (for other ranges)
Pressure Media: Compatible with 316 Stainless Steel
Current Terminal
Input Protection: Fuse 100mA / 250V
Display: Graphical display with LED backlight
Power Supply: Li-ion rechargeable battery
Transmitter Supply: 24V DC ±10% (Loop Powered)
Battery Backup: Up to 19 hours
Low Battery Indicator: Yes
Auto Power Off: After 15 minutes of inactivity
Pressure Connection: 1/4" BSP Female
Operating Temperature: 10 to 50°C
Instrument Casing: ABS Plastic
Dimensions: 250 mm x 145 mm x 45 mm (L x W x D)
Weight: 650 grams
