Static elimination time test
- Air pressure: 0.2Mpa
+ distance: 15 cm 30 cm 45 cm 60 cm
+ Static elimination time (S):
0.9 S1.3 S1.7 S2.1 S
1.0 S1.4 S2.1 S2.9 S
+ Ion balance (V):
-1 V+5 V+6 V0 V
- Air pressure: 0.4Mpa
+ distance: 15 cm 30 cm 45 cm 60 cm
+ Static elimination time (S):
0.8 S1.0 S1.3 S1.3 S
1.0 S1.3 S2.0 S2.5 S
+ Ion balance (V):
0 V+1 V+1 V0 V
- Air pressure: 0.6Mpa
+ distance: 15 cm 30 cm 45 cm 60 cm
+ Static elimination time (S):
0.8 S0 S1.4 S1.5 S
0.9 S1.4 S1.8 S2.7 S
+ Ion balance (V):
-2 V-4 V+6 V-14 V
Note:
1. Environment: 2 2 ° C, humidity 6 0 - 70%, the test method is based on ANSI / EOS / ESD - S3. 1-1991.
2. The ion is neutralized from 1000V to 10V and the ion balance voltage.
3. Working at 0.7Mpa air pressure, the noise is less than 80dB
Features:
1. The ion balance value can reach ±10V, which can quickly eliminate static electricity on charged objects.
2. The ion balance is stable and externally adjusted, which is simple and convenient.
3. Built-in silencer system with low noise.
4. The high voltage adopts capacitive coupling, which is safe and reliable.
5. 445 F gas volume is adjustable.
6. The 446 F-II can carry two loads at the same time.
