Gain: 19.9 dB
Technology: Si
Unit Weight: 37.400 mg
Mounting Style: SMD/SMT
Test Frequency: 2.6 GHz
Development Kit: TQL9093-PCB
Input Return Loss: 14 dB
NF - Noise Figure: 0.67 dB
Number of Channels: 1 Channel
Operating Frequency: 600 MHz to 4.2 GHz
Operating Supply Current: 120 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 21.7 dBm
OIP3 - Third Order Intercept: 41.5 dBm
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
