Qorvo QPA4586ASR General Purpose Amplifiers DC-4GHz Gain 19.9dB P1dB 16.3dBm NF2.7dB

Gain: 19.9 dB

Technology: SiGe

Unit Weight: 1 g

Isolation dB: 23.7 dB

Mounting Style: SMD/SMT

Test Frequency: 1.95 GHz

Development Kit: QPA4586APCK401

Input Return Loss: 16.3 dB

NF - Noise Figure: 2.7 dB

Number of Channels: 1 Channel

Operating Frequency: 0 Hz to 4 GHz

Supply Voltage - Max: 3.8 V

Supply Voltage - Min: 3.2 V

Operating Supply Current: 45 mA

Operating Supply Voltage: 3.2 V to 3.8 V

P1dB - Compression Point: 16.3 dBm

OIP3 - Third Order Intercept: 30.1 dBm

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
