Gain: 2 dBi, 5 dBi
VSWR: 2:1
Style: I-Bar
Width: 6 mm
Length: 45 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Application: Wireless Applications, IoT Devices, M2M, Security, Transportation
Power Rating: 2 W
Mounting Style: Adhesive Mount
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.925 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: IPEX MHF
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), DSRC
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
