MT-7068-T Transmitter Specifications
Tone frequency 1kHz
Tone mode ONE/TWO-note tone
Compatible connectors RJ-45/RJ-11/USB/F/BNC/
RCA/Alligator Clips
Continuity test <300Ω
Talk battery voltage 6V into 600Ω
Function selection 5-position rotary switch
Cable map indication 8 LED indicators
Voltage protection 100V
Low battery display 6.5V
Battery type 9V (6F22)
Dimension (LxWxD) 140x70x30mm
MT-7068-R Receiver Specifications
Frequency 1kHz
Compatible connectors RJ-45/RJ-11/USB/F/BNC/RCA
Ear jack 1
Signal status indication 8 LED indicators
Cable map indication 8 LED indicators
Low battery display 6.5V
Battery type 9V (6F22)
Dimension (LxWxD)
250x5
