Power: 30KW
Current: 0~30A/0~300A
Voltage: 0~1000V
Min.Operation Voltage: 10V@300A
Protections:
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 104%
Over Voltage Protection (OVP): 104%
Over Temp Protection (OTP): Yes
CC mode:
Range: 30A/300A
Resolution: 0.5mA/5mA
Accuracy: ±0.1%
CR mode:
Range: 4000~3.333Ω/3.333~0.0336Ω
Resolution: 5.0005uS/0.056mΩ
Accuracy: ±0.2%
CV mode:
Range: 10~1000V
Resolution: 16mV
Accuracy: ±0.05%
CP mode:
Range: 3000W/30000W
Resolution: 50mW/500mW
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 100V/100~1000V, ±0.025%
Current : 0 ~ 30A/30~300A, ±0.1%
Power : 3000W/30000W, ±0.125%
Short circuit current: 300A
Dimension (HxWxD): 1197 x 647 x 766 mm
Weight: 340 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
