Power: 40KW
Current: 0~128A/0~1280A
Voltage: 0~600V
Min.Operation Voltage: 10V at 1280A
Protections:
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 104%
Over Voltage Protection (OVP): 105%
Over Temp Protection (OTP): Yes
CC mode:
Range: 128A/1280A
Resolution: 2.048mA /20.48mA
Accuracy: ±0.1%
CR mode:
Range: 5625Ω ~ 0.46875Ω / 0.46875Ω~0.00787Ω
Resolution: 35.5μs/ 0.007875mΩ
Accuracy: ±0.2%
CV mode:
Range: 600V
Resolution: 10mV
Accuracy: ±0.05%
CP mode:
Range: 4000W/40000W
Resolution: 64mW/640mW
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 60V/60~600V, ±0.025%
Current : 0 ~ 128A/128~1280A, ±0.1%
Power : 10000W/40000W, ±0.125%
Short circuit current: 1280A
Dimension (HxWxD): 1509x647x766mm
Weight: 430kg
Optional interface: GPIB, RS232, USB, LAN
