Power: 18KW
Current: 0 ~ 180A; 0 ~ 1800A
Voltage: 0 ~ 150V
Min. Operating Voltage: 0.7V at 1800A
Protections: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp Protection (OTP)
Constant Current Mode Range: 180A; 1800A
Constant Resistance Mode Range: 5000Ω~0.0833Ω; 0.0833Ω~0.0004Ω
Constant Voltage Mode Range: 150V
Constant Power Mode Range: 1800W; 18000W
Constant Voltage Mode + Constant Current Mode Range: 150V; 1800A
Constant Voltage Mode + Constant Power Mode Range: 150V; 18000W
Surge & Normal current: 0~1800A
Dynamic Mode:
- Timing: 0.010~9.999 / 99.99 / 999.9 / 9999mS
- Current: 0~180A; 180~1800A
Measurement
- Voltage Read Back Range (5 Digital): 0 ~ 15V; 15 ~ 150V
- Current Read Back Range (5 Digital): 0~180A; 180~1800A
- Power Read Back Range: 18000W
Typical Short Resistance: 0.0004Ω
Maximum Short Current: 1800A
Load ON Voltage: 0.25 ~ 62.5V
Load OFF Voltage: 0 ~ 62.5V
Power Consumption: 1100VA
Dimension (HxWxD): 761x444x763mm
Weight: 124 kg
Temperature: 0~40℃
