Power 300W, 600W max
Current 12A / 24A max
Voltage 500V
PROTECTIONS
Over Power Protection(OPP) 105%
Over Current Protection(OCP) 105%
Over Voltage Protection(OVP) 105%
Over Temp Protection(OTP) yes
Constant Current Mode
Range: 0 ~ 1.2A, 0~12A
Resolution 0.02mA, 0.2mA
Accuracy 0.1%
Constant Resistance Mode
Range 50-3000KΩ/0.5Ω~50Ω
Resolution: 0.000333mS/0.8333mΩ
Accuracy ± 0.2%
Constant Voltage Mode
Range 0 ~ 60V/0~500V
Resolution 0.001V, 0.01V
Accuracy ± 0.05%
Constant Power Mode
Range 0 ~ 30W/0-300W
Resolution 0.001W /0.01W
Accuracy ± 0.5%
Constant Current + Constant Voltage Mode
Range 500V/12A
Resolution 0.01V/0.2mA
Accuracy 1%
Constant Power + Constant VoltageMode
Range 500V/ 300W
Resolution 0.01V, 0.01W
Accuracy 1%
Dimension(HxWxD): 143 x 108 x 412 mm
