SPECIFICATIONS
Power (kVA) : 20kVA
Circuit Type : IGBT/PWM type
INPUT :
Phase : Three Phase
Wave : Sine
Voltage : 220V ± 15%
Frequency Range : 47-63 Hz
Power Factor : 0.85
OUTPUT
Phase : Single
Wave : Sine
Voltage : Low : 5V~150.0V L-N / High : 10V~300.0V L-N
Frequency Range : : 45~500Hz
Frequency Regulation : ≦ 0.01 %
Max current : 83.3/166.7
Line Regulation : <1%
Load Regulation : ± 1% (Resistive Load)
THD : ≦ 2% (Resistive Load)
Efficiency : ≧ 90%
Response Time : ≦ 2ms
Crest Factor : 3: 1
Protection : OVP, UVP, OCP, OPP, OTP and Short Circuit Protection
Indicator :
Voltage : 0-300V
Resolution: 0.01V ( < 100V )
0.1 ( ≧ 100V )
Accuracy: 0.5% F.S. + 5 Counts
Current : A
Range : 0-50A ( ≦ 5kW)
0-700A ( > 5kW)
Accuracy: 0.5% F.S.+ 5 Counts
Power : W
Range : 0-5kW ( ≦ 5kW)
0-75kW ( > 5kW)
Accuracy: 0.5% F.S.+ 5 Counts
Frequency : 45-500Hz
Resolution: 0.1Hz;
Accuracy: 0.5% F.S. + 2 Counts
Power factor : 0-1 , accurate : 2%
Time : 1s-99h
Default :
Voltage : 0-300V (0.1V) accurate 1%
Frequency : 45-500Hz (0.1Hz) accurate 0.01%
Time : 1s-99h
General program memory : 10 sets
Step program memory : 24 sets
Gradual program memory : 12 sets
Mode control :
Keyboard control
Remote control : RS232, RS485
Opertional Temp. : 0-45 độ C
Humidity : 0-90%
Altitude : < 1500m
Dimensions (HxWxD) :600x880x1440
Weight(kg): 305kg
