INPUT
Phase: 3Ø / 3Wire + G
Voltage: 380Vac ±15% (option: 400Vac, 240Vac or 480Vac)
Frequency: 47 - 63Hz
Max. Current: 3145.6A
Power Factor: ≥0.9(Max. Power)
OUTPUT
Power: ( VA ): 1500kVA
Phase: 3Ø / 4 Wire + G
Voltage Ranges
Low (V): 0V-155.0V(L-N)
High (V): 0V-310.0V(L-N)
Frequency Range: A : 45-500Hz;B : 45-120Hz
Max. Current (RMS)
Low (A): 4166.7A
High (A): 2083.3A
MEASUREMENT
Voltage Range: 0V-310.0V
Frequency Range: 45.0-500.0Hz
Current Range (RMS): 0 - 4166.7A
Power Range: 0 - 1500kW
GENERAL
Efficiency: ≥85% at Max. Power
HMI: Touch Screen, 7" Color TFT LCD
Opertional Temperature: 0°C~45°C
Humidity: 0~90% ( Non condensing )
Altitude: < 1,500m
Dimensions (H x W x D): (for 380V input voltage, Other voltage - Special order Options)
2200 x 12990 x 1590 mm
86.6 x 511.4 x 62.6inch
Weight: 18720kg / 8489.8lbs (for 380V input voltage, Other voltage - Special order Options)
