Output Power: Single Phase, 1.5 kVA
Output Voltage (Low Range): 0 to 175 V
Output Voltage (High Range): 0 to 350 V
Output Voltage (Optional): 0 to 620 V, 0 to 1240 V
Output Frequency: 5 to 2000 Hz (Version A)
Total Harmonic Distortion (THD): ≤ 0.3 % at 5 to 100 Hz, ≤ 0.5 % at 101 to 500 Hz, ≤ 0.8 % at 501 to 1000 Hz, ≤ 1.5 % at 1001 to 1500 Hz, ≤ 2 % at 1501 to 2000 Hz (Resistive Load)
Load Regulation: ≤ 0.07 % F.S. (Resistive Load)
Crest Factor: ≥ 3
Inrush Current: ≥ 4.5 times of maximum output current (RMS), optional 9 times
Response Time: ≤ 300 μs
DC Output Voltage: 0 to 240 V / 0 to 480 V
Input Voltage: 90 to 264 VAC / 196 to 264 VAC
Input Frequency: 47 to 63 Hz, optional 400 Hz
Interfaces (Standard): RS232 / RS485 / Ethernet / USB / PLC Remote In & Out
Interfaces (Optional): GPIB / Analog
Dimensions (H × W × D): 89 × 442 × 495 mm
