Voltage generators
Setting range:
4‐phase ac(L‐N): 4×0~300V
1‐phase ac(L‐L): 1×0~600V
dc (L‐N): 4×±0~300V
dc (L‐L): 1×±0~600V
Power
4‐phase ac(L‐N): 4×75VA typ., at 300V/ 4×50VA guar., at 300V
3‐phase ac(L‐N): 3×100VA typ., at 300V/ 3×85VA guar., at 300V
1‐phase ac(L‐L): 1×200VA typ., at 600V/ 1×170VA guar., at 600V
dc (L‐N): 4×100W at 300 V
Accuracy: error < 0.08% rd.+0.02% rg. guar./ error < 0.02% rd.+0.01% rg. typ.
Ranges: 300V
Resolution: 10mV for 300Vac
Distortion: < 0.05 % typ.; (< 0.1 % guar.)
Current generators
Setting range:
6‐phase ac(L‐N): 6×0~15A
3‐phase ac(2L‐N): 3×0~30A
1‐phase ac(6L‐N): 1×0~90A
dc (L‐N): 6×±0~10A
dc (6L‐N): 1×±0~60A
Power
6‐phase ac(L‐N): 6×150VA at 15A
3‐phase ac(2L‐N): 3×240VA at 30A
1‐phase ac(6L‐N): 1×450VA at 90A
1‐phase ac(L‐L): 1×450VA at 30A
Accuracy: error < 0.08% rd.+0.02% rg. guar./ error < 0.02% rd.+0.01% rg. typ.
Ranges: 15A or 30A
Resolution: 1mA
Distortion: < 0.05 % typ. (< 0.1 % guar.)
Auxiliary DC supply
Voltage range: 0~300V
Power: 88W at 110V, 176W at 220V,120W at 300V
Accuracy: error < 0.1% rg. typ. (<0.5% rg. guar.)
12 binary inputs, 8 binary outputs
Operation temperature: 0~+50°C
Storage temperature: ‐25~+70°C
Relative humidity: 5~95% non‐condensing
Weight: 20kg
Dimensions (W x H x D): 360mm ×157mm×367mm
