Current output: 3 x 0~60A RMS
Max. output power: >800VA (60A output)
Input signal, Gain:
Standard: Input signal: 0 ~ 5V RMS (±7.07Vpek), Gain: 12A/V
Option 1: Input signal: 0 ~ 7.07V RMS (±10Vpek), Gain: 9A/V
Option 2: Input signal: 0 ~ 11.31V RMS (±16Vpek), Gain: 6A/V
Current accuracy: 0.2%(0.5-60A)
Current typical accuracy: <0.1%
Differential input impedance: 20k
Harmonic distortion ratio: ≤ 0.2%
Linearity: ≤ 0.2%
Phase accuracy: 0.2°
Frequency range: DC-5kHz±1dB
Step response: <20us
Input/output delay: <20us
Voltage output: 4 x 0~120V RMS
Max. output power: >60VA (120V output)
Input signal, Gain:
Standard: Input signal: 0 ~ 5V RMS (±7.07Vpek), Gain: 25A/V
Option 1: Input signal: 0 ~ 7.07V RMS (±10Vpek), Gain: 20A/V
Option 2: Input signal: 0 ~ 11.31V RMS (±16Vpek), Gain: 12A/V
Voltage accuracy: <0.1%(5V~120V)
Voltage typical accuracy: <0.05%
Differential input impedance: 20k
Harmonic distortion ratio: ≤0.1%
Linearity: ≤0.1%
Phase accuracy: 0.2°
Frequency range: DC-5kHz±1dB
Step response: <20us
Input/output delay: <20us
Power supply: Single phase 110/220V AC 50/60 Hz
Chassis: 4U
